Bearing UCP 207

The​ UCP 207 is a medium-weight mounting pillow block ball bearing unit that can support a 35mm rotating shaft in industrial, agricultural, and material handling equipment. Indeed, it is amongst the most widely used bearing units of the 30-40mm bore size class, mainly due to its balance of load capacity, simplicity of installation, as well as sturdy cast iron construction.
This bearing unit features the combination of two separate components into one single ready-to-mount unit: the UC 207 insert ball bearing - a wide-inner-ring deep groove ball bearing with extended inner ring - and the P 207 cast iron pillow block housing, which provides a two-bolt foot-mounted enclosure. Altogether, they form a complete shaft support solution which can be ordered, stocked, and installed as a single unit.
When it comes to manufacturers worldwide, SKF is still the leading choice of supplier for the UCP 207. SKF was the first to introduce the insert bearing unit concept and still leads the way in terms of dimensional accuracy, load ratings, sealing effectiveness, and shaft holding ability. The SKF UCP 207 is produced in accordance with JIS B 1558 standards and is completely interchangeable with equivalent units from NTN, NSK, Timken, FAG, Koyo, and ​FYH.

Pillow Block Bearing UCP 207

The main aim of designing the Pillow Block Bearing UCP-207 was to ensure that it provided smooth and efficient running with very little need for maintenance. Due to its self-aligning feature, it is able to withstand a small amount of misalignment of the shaft. Throughout its period of use, its performance is stable. It is pre-lubricated when leaving the factory, and there is also an added advantage of being able to lubricate it during its period of use. Thus, it is good for re-lubrication if needed.

In addition to this, its construction ensures that it is able to withstand pressures during operation without changing its position. Thus, it is good for long periods of work. Due to its balance and reliability, the Pillow Block Bearing UCP-207 has been widely used in industries where there is a need for reliable shafts. As one of the emerging suppliers of bearings in India, we have a wide range of UCP bearings, such as UCP 208, UCP 209, UCP 210, up to UCP 219.

Additional​ Features

The UCP-207 bearing has almost all the important factors to be considered for efficient usage in industries:

• Housing of the smallest size, which allows the usage of this bearing even in the most compact spaces, such as a cabinet of a diabola-type shot blasting machine.

• A quiet rotation mechanism, which reduces the noise level during the operation of the machine.

• Improved grease retention, which ensures the longevity of grease for a relatively long period.

• Very strong base support to hold the bearing firmly in place during the operation of the machine.

• An anti-corrosive coating of the surface, which increases the longevity of the bearing even in damp environments.

UCP 207 vs UCP Series — Size Comparison
